TM-704-PC/PCF
- 1、Pin code capacity : 32 sets (4 to 8 digits).
- 2、User card capacity: 32 sets.
- 3、Programming code : 1 set (4 to 8 digits).
- 4、Fingerprint capacity：200 sets (TM704-PCF only).
- 5、Key: 2.
- 6、Dimension (W*H*D): Exterior lock body 349 mm x 79 mm x 63 mm, Interior lock body 349 mm x 79 mm x 70mm.
- 7、Finish: Two-tone Black and Silver.
- 8、Door bore hole : Mortise.
- 9、Door thickness : 1-3/4"(45 mm) to 3-1/2”(85 mm).
- 10、Backset : 2-3/8"(60 mm) and 2-3/4"(70 mm)
- 11、Touch Screen Back-light color: Blue.
- 12、Power: Four AA 1.5V alkaline batteries.
- 13、Operation temperature: -31°F to 150.8°F (-35℃ to 66℃ )
- (Temperature tolerance could vary due to different weather conditions).
Share
Great Convenience
- Simply touch the screen to operate.
- Holds up to 32 user codes / cards & 200 fingerprints(4-in-1)
- Volume control (adjustable to work with environments).)
- Auto-lock with adjustable delay (5-99 seconds).
- Back-up mechanical keyway.
- Passage mode (disables auto-lock ).
Uncompromised Security
- 4-digit random guiding code prevents code-probing.
- Touch screen is temporarily disabled after 4 consecutive incorrect entries.
- Night latch provides extra security.
Easy Installation
- Fits most standard door preparations.
- Voice-guided programming process.
- Graphic step-by-step installation instruction, and user manual.
